NCS - TORNADO-IV-DUO 2007

PASS on IMAGE TO ENLARGE	TORNADO-IV/DUAL 2 CORE Technical features CPU Intel Core Solo, Core Duo and Core 2 Duo processor with 533/667 MHz FSB; speed up to 2.33 (2.0) GHz. Intel 945GM Chipsets Two 240-pin DDR2 DIMM Socket support un-buffered non-ECC DDR2 400/533/667 up to 4GB Intel 82573L PCI Express Gigabit LAN X 2 Support LVDS /VGA Display and one x16 PCI Express slot CompactFlash Socket 4 Serial Ports - 1 LPT - 6 USB 2.0 Intel® 82573L PCI Express Gigabit Ethernet Controller x 2 supporting two GbE LAN ports FDC HDD - PS/2 MOUSE and KEYBOARD ports FLASH DISK up 6Gb CRT - LVDS TFT 18/24 bit 2 x SATA ports, support Raid 0,1, bandwidth: 150 MB/s AC97 Audio CODEC IrDA Tx Rx P.S. 110/220 Vac or DCD/DC +12 Vdc or +24 Vdc
PASS on IMAGE TO ENLARGE	TORNADO-IV/DUAL 2 CORE with IP65-NEMA4/4X with 20 push-button
on IMAGE TO ENLARGE	TORNADO-IV/DUAL 2 CORE SIDE CONNECTORS avaiable expansion module BUS/2-PCI (adds 32 mm - 1.25" to depth)
NCS reserve the right to make changes in the specifications without notice. NCS assume no liabilities arising from the application or use of any product described herein. NCS assume no obligation to correct any errors herein or advise the use of this text of any corrections if such to be made.
