Do You want cost-effective speed and reliability ?
If so, your future is now with the N.C.S. Computer Group
WELCOME. The new SYSTEM with the P4 CORE DUO CPU. The TORNADO-IV DUAL CORE is designed to operate in very hostile environments, where an office PC or an assembled PC does not provide a high level of reliability.
FEATURES :
IntelŪ Core Solo and (optional) Core 2 Duo family processors Intel 945GM Chipset, up to 2.33 GHz with 667MHZ FSB
2 x 240-pin DIMM socket, up to 4GB SDRAM
1 x PCI Slot, 1 x PCI Expressx16 Slot
Display Chipset IntelŪ 945GM integrated graphics solution with Up to 64 MB of dynamic video
memory allocation CRT up to 1600x1200 at 85 Hz, 2048x1536 at75Hz,
LVDS PANEL up to 1600x1200, Wide Screen Resolution support 848x480 and 1366x768
TV Out - Support S-Video up to 1024 x 768 NTSC/PAL and 1080p HDTV
Ethernet Controller IntelŪ 82573L PCI Express x 2 supporting two GbE LAN ports
Audio AC97 + CODEC Realtek RTL655
6 x USB 2.0 port, 4 RS-232, Parallel ports, 1 x PS/2 K/M, 8 GPIO TTL, IrDA
1 internal CompactFlash socket , 2 x SATA ports, support Raid 0,1, 1 x IDE
Operating Temperature 0°C ~ 60°C
Operating RH 10%~90%, non-condensing
Our System TORNADO IV is available with O.S. WIN XPe on the FLASH DISK
We offer models with TFT from 6.4" up to 23"
Power Supply 85-264 Vac, +12/+24Vdc.
IP65 Front Panels can be in both aluminium and Stainless Steel.
Many options are proposed with our systems: EXP BUS/2-PCI, several models of industrial keyboards, TOUCH SCREEN, MOUSE, TRACK-BALL, FLASH DISK and for Marine Systems HB TFT (up to 1600 mē)
N.C.S. is compliant with the European Union Directive "RoHs" in our manufacturing process.
|
|
|
